Teaching Booleans About Versions: A Theory-Augmented BDD Library in OCaml

What if checking whether two formulas with a million nodes are logically equivalent took exactly one machine instruction? Binary Decision Diagrams (BDDs) make this possible. They give you a canonical representation of boolean functions (two logically equivalent formulas always produce the exact same structure), which turns equivalence checking into a pointer comparison.

Theo is an OCaml library that implements BDDs with two key extensions: complement edges for compact representation, and theory support for reasoning about linear orders and equality. Consider a package manager checking whether (ocaml >= 4.14 AND dune >= 3.0) OR (ocaml >= 5.0) is compatible with ocaml < 5.0. With Theo, you write this directly using version constraints as atoms, and the engine automatically simplifies: it knows ocaml >= 4.14 is redundant when ocaml >= 5.0 holds, detects that the second disjunct contradicts ocaml < 5.0, and can find the simplest satisfying assignment (ocaml >= 4.14, ocaml < 5.0, dune >= 3.0).

This post walks through the main implementation ideas behind Theo: the complement edge representation, hash-consing via weak tables and ephemeron-based memoization, theory-aware simplification during BDD construction, and several algorithmic techniques (contextual restriction, minimal witness extraction, construction-free entailment checks, and conversion back to readable formulas) that make the library practical.

From truth tables to shared diagrams #

A boolean function over n variables can be represented as a truth table with 2^n rows, or equivalently as a binary decision tree: at each node, you test a variable and branch left (false) or right (true), until you reach a leaf (0 or 1). The problem is that this tree is exponentially large.

A Binary Decision Diagram (BDD) is a compressed version of this tree, obtained by two reductions:

1. Merge identical subtrees. If two nodes have the same variable, same low child, and same high child, keep only one copy.
2. Eliminate redundant tests. If a node’s low and high children are the same subtree, skip the test entirely.

Here is a OR b going through both reductions:

Decision tree:          Merge identical subtrees:    Eliminate redundant b:

       a                       a                          a
      / \                     / \                        / \
     b   b        →          b   b            →         b   1
    / \ / \                 / \ / \                    / \
   0  1 1  1               0 (1)(1)(1)                0   1

 3 tests, 4 leaves:     3 tests, 2 leaves:         2 tests, 2 leaves:
 7 nodes.               5 nodes: (1) is a single   4 nodes.
                        shared node, drawn thrice.

Merging collapsed the three 1 leaves into a single shared node. That left the right b testing a variable with both branches leading to the same node: a redundant test, eliminated. Seven nodes became four.

When you additionally fix a variable ordering (every path from root to leaf tests variables in the same order), the result is called a Reduced Ordered BDD (ROBDD). The key theorem is that ROBDDs are canonical: for a given variable ordering, every boolean function has exactly one ROBDD. Logical equivalence becomes pointer equality. O(1).

The core operation on BDDs is ITE (if-then-else): given three BDDs f, g, h, compute the BDD for “if f then g else h”. Every boolean connective reduces to ITE:

• and(f, g) = ite(f, g, 0)
• or(f, g) = ite(f, 1, g)
• not(f) = ite(f, 0, 1)

Computing ITE rests on one more notion. The cofactor of a function f with respect to a variable x is f with x fixed to a constant: f|x=1 (fix x to true) and f|x=0 (fix x to false). Shannon decomposition says that any function can be rebuilt from its two cofactors:

f  =  (x AND f|x=1) OR (NOT x AND f|x=0)

On a BDD, cofactors with respect to the root’s own variable are free: they are simply the high and low children. And if the root tests a variable that comes later in the ordering, the function does not depend on x at all, so both cofactors are the BDD itself.

The ITE algorithm applies this decomposition recursively: pick the topmost variable x across all three inputs, decompose each input into its cofactors, recurse on both branches, and combine the results into a new node. With memoization, this runs in O(|f| * |g| * |h|) time.

Negation for free #

In a standard BDD, negation requires traversing the entire structure: you rebuild every node, with the 0 and 1 terminals swapped. This is O(n) where n is the number of nodes. For a data structure built around efficiency, that’s disappointing.

Complement edges solve this by allowing edges to carry a negation flag. The idea comes from Brace, Rudell, and Bryant [1]: instead of building a separate BDD for not f, just mark the edge to f as complemented.

Negation becomes O(1).

The trick is maintaining canonicity. With unrestricted complement edges, the same function could be represented in multiple ways. Theo enforces a canonical form through two invariants:

1. Only one terminal node. There is only False; truth is represented as Not False.

2. The low branch is always positive. Complement edges appear only on the high branch (via negate_high) or at the root (via Not). This prevents multiple representations of the same function.

Here is the actual type definition:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12

type _ u =
  | False : positive u
  | If : {
      atom : atom;
      high : positive u;
      negate_high : bool;
      low : positive u;
      id : int;
    } -> positive u
  | Not : positive u -> negative u

type t = Bdd : _ u -> t [@@unboxed]

The phantom types positive and negative enforce at the type level that If nodes store positive (non-complemented) subtrees for both high and low. The complement is carried by the negate_high boolean for the high branch, and by the Not wrapper at the root. The Bdd wrapper that hides the polarity is [@@unboxed]: it exists only at the type level and costs nothing at runtime.

To see what this buys us, here is a AND b in both representations:

Standard BDD:           Complement edges:

      a                       a
     / \                     / \
    0   b                   F   b
       / \                     / \~
      0   1                   F   F

Two terminals (0, 1).   One terminal (F).
                        ~ = complement edge: ~F reads as True.

Now negate it. In the standard BDD, you’d walk every node and flip the leaves. With complement edges:

NOT (a AND b):

    NOT
     |
     a              Same nodes. Just wrapped in NOT.
    / \
   F   b
      / \~
     F   F

In code, negation is just:

1
2
3
4
5

let not u =
  match u with
  | Bdd (Not u) -> Bdd u       (* double negation cancels *)
  | Bdd False   -> true_        (* not false = true *)
  | Bdd (If _ as f) -> Bdd (Not f)

The split helper decomposes any BDD into its polarity and positive core, which is used throughout the implementation:

1
2
3
4
5

let split (Bdd u) =
  match u with
  | Not n  -> (true, n)
  | If _ as n -> (false, n)
  | False as n -> (false, n)

Since negation is free, De Morgan’s law is free. Which means Theo has no dedicated OR algorithm. Apart from a few fast paths for terminals and other trivial cases, the entire implementation is:

1

let or_ u v = not (and_rec (not u) (not v))

Three calls to not, each O(1), plus one and_rec. One recursive algorithm eliminated.

This representation also has a consequence for the ITE algorithm: ite normalizes its arguments before recursing. If f is negative, swap g and h; if h is negative, negate the result and recurse with not g. This doesn’t affect canonicity (which is guaranteed by hash-consing and the node invariants), but it collapses multiple argument triples that represent the same logical computation into a single canonical form. Without normalization, ite(not f, g, h) and ite(f, h, g) would occupy separate cache entries despite computing the same thing. With it, they resolve to the same lookup.

Same formula, same pointer #

Hash-consing is the technique of ensuring that structurally equal values are represented by a single object in memory. For BDDs, this is what turns the canonicity guarantee into an O(1) equality check: if two BDDs represent the same function, they are literally the same pointer.

Weak tables, strong guarantees #

But there’s a tension: if you store every node ever created in a global table, nothing gets garbage-collected. Your BDD library slowly eats all available memory.

Theo resolves this with OCaml’s Weak.Make: a hash table that holds weak references to its entries. The GC can reclaim any entry that is no longer referenced elsewhere. You get structural sharing without memory leaks.

The pattern is the same for atoms and nodes. Here is the node constructor:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10

let ite atom high negate_high low =
  let id = !next_id in
  let node =
    WeakTbl.merge weak_tbl (If { atom; high; negate_high; low; id })
  in
  match node with
  | If { id = id'; _ } when Int.equal id id' ->
      next_id := !next_id + 1;
      node
  | If _ | False -> node

The merge function is the key operation: it looks up the candidate node in the weak table. If an equal node already exists, it returns the existing one (and the candidate, including its fresh id, is discarded). If no equal node exists, the candidate is inserted and its id becomes permanent. The check Int.equal id id' detects which case occurred.

The same pattern applies to atoms (Atom.WeakTbl), ensuring that the atom for “ocaml, less than 5.0” exists at most once in memory. Since atoms are compared by physical equality everywhere in the BDD engine (atom == v), this is what makes cofactor decomposition fast.

Caches that forget #

BDD operations rely heavily on memoization: without caching, the ITE algorithm would repeatedly recompute the same subproblems, exploding to exponential time. The standard approach is a hash table keyed by the operation’s inputs.

A regular hash table holds strong references to its keys, though. If the keys are BDD nodes, the cache keeps them alive, defeating the whole point of weak hash tables. We’d need manual eviction, which is fragile and error-prone.

What if the cache could clean up after itself?

This is exactly what ephemerons provide. An ephemeron is a key-value pair where the key is held weakly: if the key object is collected by the GC, the entire entry (including the value) becomes reclaimable. OCaml’s standard library provides Ephemeron.K1, Ephemeron.K2, and Ephemeron.Kn for ephemerons with one, two, or n keys.

Theo uses four ephemeron-based caches, each with a design tailored to its use case:

The ITE cache (Ephemeron.Kn.Make with 3 keys) stores ite(f, g, h) results. Since g can appear in either polarity (positive or negative) while f and h are always positive after normalization, the cache uses a polarity cell trick: it keys on (f, |g|, h) (where |g| is the positive core of g) and stores both the positive and negative results in the same cell:

1
2
3
4

type 'a polarity_cell = {
  mutable pos : 'a option;
  mutable neg : 'a option
}

This avoids duplicating cache entries for ite(f, g, h) and ite(f, not g, h).

The binary cache (Ephemeron.K2.Make) takes this further. It stores AND results for all four polarity combinations of its two operands in a single entry:

1
2
3
4
5
6

type cell = {
  mutable pp : t option;  (* |u| AND |v|     *)
  mutable pn : t option;  (* |u| AND NOT |v| *)
  mutable np : t option;  (* NOT |u| AND |v| *)
  mutable nn : t option;  (* NOT |u| AND NOT |v| *)
}

Remember that or_ u v = not (and_rec (not u) (not v))? When Theo computes an OR, it calls and_rec on the negated inputs, and the result lands in the nn slot of the very cell whose pp slot a direct AND of the same operands would fill. One cache entry serves both operations.

The simplify cache (Ephemeron.K1.Make) stores theory simplification results keyed by a single BDD node. This is used during theory-aware node construction, discussed next.

The constant cache (Ephemeron.Kn.Make with 3 keys) memoizes the construction-free entailment checks discussed later. It uses the same polarity-cell trick as the ITE cache, but stores three-valued verdicts instead of BDDs.

Together, weak tables and ephemerons form a self-managing memory system. BDD nodes live in weak hash tables: when application code drops all references to a node, the GC reclaims it. Ephemeron caches hold weak references to those same nodes as keys: when a node dies, all cache entries that depended on it become reclaimable too. No manual cache invalidation, no memory leaks, no bookkeeping. The GC does all the work.

Beyond booleans #

Theo’s atoms aren’t just booleans: they’re constraints like ocaml < 5.0 or name = "foo", and the engine knows what that means.

Standard BDDs reason about pure boolean variables. But a package manager needs to compare version numbers, a type checker tracks string labels, a configuration system deals with enumerated values. You could encode these as booleans, but you lose the domain structure and the BDD cannot exploit the semantics. Theo takes a different approach: atoms carry theory predicates, and the engine uses their semantics to simplify formulas during construction.

Atoms with meaning #

The engine classifies theory predicates into three categories, each with different simplification rules:

1

type _ category = Bool | Leq | Eq

• Bool: plain boolean variables. No theory reasoning.
• Leq: linear order bounds (< limit or <= limit). The engine knows that a tighter bound implies a weaker one.
• Eq: equality constants (= value). The engine knows that equality with one value falsifies equality with any other.

A crucial design choice is atom ordering: atoms are sorted first by variable, then by payload. For Leq atoms, this means all bounds for the same variable are clustered together and sorted by their bound value. The engine encounters tighter bounds before weaker ones, which is what makes the pruning described in the next section possible.

The OCaml encoding. At the type level, a theory is a module implementing comparison, hashing, and pretty-printing for atom descriptors:

1
2
3
4
5
6
7

module type Theory = sig
  type _ t
  val equal : _ t -> _ t -> bool
  val compare : _ t -> _ t -> int
  val hash : _ t -> int
  val to_string : _ t -> string
end

The BDD engine is parameterized by a theory via the Make functor. Theo provides three building blocks:

• Void is the trivial theory: type _ t = unit. It carries no descriptors, so Make(Void) gives you a pure boolean BDD.

• Leq(C) takes a comparable type and builds a theory for linear orders. Each descriptor is a Bound { limit; inclusive }, representing < limit or <= limit.

• Eq(C) builds a theory for equality. Each descriptor is a Const value, representing = value.

To mix theories in the same BDD, Combine(A)(B) merges two theories into a sum type:

1

type 'a t = Left : 'a A.t -> 'a t | Right : 'a B.t -> 'a t

Since the output of Combine is itself a Theory, it can be nested: Combine(Combine(A)(B))(C) composes three theories. A typical setup for a package manager:

1
2
3
4

module VersionLeq = Leq(Version)
module StringEq   = Eq(String)
module MyTheory   = Combine(VersionLeq)(StringEq)
module MyBDD      = Make(MyTheory)

Internally, an atom combines a variable, a category, and a payload:

1
2
3
4
5
6

type atom = Atom : {
  var : 'kind Var.t;
  category : 'kind category;
  payload : 'kind payload;
  id : int;
} -> atom

For example, the atom for ocaml < 5.0.0 would have category = Leq and payload = Theory (Bound { limit = v5_0_0; inclusive = false }).

Notice the existential type: Atom packs a 'kind type variable that ties var, category, and payload together, then hides it. This is a GADT pattern that lets a single atom type hold heterogeneous payloads (boolean flags, version bounds, string constants) while ensuring at the type level that a version variable never receives a string payload. The view_constraint function later unpacks the existential for pattern matching.

Pruning what you already know #

When the BDD engine decomposes a formula along an atom like ocaml < 4.14, it knows that in the high branch (where ocaml < 4.14 holds), any atom for the same variable with a weaker bound is redundant. ocaml < 5.0? Automatically true. No need to test it.

This is implemented through the cofactors function, which computes the high and low branches of a BDD with respect to a given atom:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14

let cofactors v (t : t) =
  let negate_t, u = split t in
  match u with
  | If { atom; high; negate_high; low; _ } ->
      if atom == v then
        (* Direct match: decompose normally *)
        let h = ... in
        let l = ... in
        (h, l)
      else
        (* Not a direct match: apply theory simplification *)
        let simplified = prune v u atom high negate_high low negate_t in
        (simplified, t)
  | False -> (t, t)

Recall that for plain boolean atoms, a mismatch between the decomposition atom and the BDD’s top atom means the function does not depend on that atom, and both cofactors are just t itself. Theory atoms are subtler: when the two atoms differ but constrain the same variable, the prune function applies theory-specific simplification. Notice the asymmetry in the return value: only the high cofactor is simplified, while the low cofactor is t unchanged. This is because the decomposition atom has a tighter bound (it comes first in the ordering), so when it’s true it implies the BDD’s top atom, but when it’s false, the top atom is still undecided, and the BDD stays as is.

The prune function:

1
2
3
4
5
6
7
8

let prune (Atom a) (u : positive u) (Atom atom) high
    negate_high low negate_result : t =
  if a.var <> atom.var then with_polarity negate_result u
  else
    match a.category with
    | Bool -> with_polarity negate_result u
    | Leq -> with_polarity (negate_result <> negate_high) high
    | Eq -> with_polarity negate_result (simplify_node (Atom a) low)

For the Leq category: because atoms for the same variable are sorted by bound value, if we are decomposing on ocaml < 4.14 and encounter a node testing ocaml < 5.0, we know the first implies the second. The node can be replaced by its high branch (the case where ocaml < 5.0 holds). This is the line Leq -> with_polarity (negate_result <> negate_high) high.

For the Eq category: if we know name = "foo", then any node testing name = "bar" is resolved to false (take the low branch). But there might be several such nodes in sequence (name = "bar", then name = "baz", then name = "qux"), all for the same variable, all falsified by the equality constraint. The simplify_node function follows the chain of low branches, skipping every atom on the same variable, until it reaches a node for a different variable (or a terminal). This collapses an entire sequence of equality tests into a single step.

The make_node function, which constructs the actual BDD node, applies the dual check. prune simplifies during cofactor decomposition (top-down); make_node checks during node construction (bottom-up). After computing the high and low branches, it asks: “if this atom were true, would theory simplification reduce the low branch to equal the high branch?” If so, the new node is redundant and is eliminated, returning the low branch directly:

1
2
3
4
5
6
7
8
9

let make_node atom high low =
  if equal high low then high
  else
    match low with
    | Bdd (If { atom = l_atom; high = l_high; negate_high; low = l_low; _ }) ->
        if check_simplification atom l_atom l_high negate_high l_low high
        then low  (* redundant: theory says high = simplified low *)
        else ...  (* construct the node normally *)
    ...

For instance, suppose we try to build a node testing ocaml < 4.14 with high = True and low = the BDD for ocaml < 5.0. Since ocaml < 4.14 implies ocaml < 5.0, the high branch (True) matches what simplifying the low branch under that assumption would produce. The ocaml < 4.14 test is redundant (the weaker bound ocaml < 5.0 already captures the behavior), so make_node returns the low branch unchanged.

A concrete example. Consider computing ocaml < 4.14 AND ocaml < 5.0. Without theory awareness, the AND would produce a two-node BDD. With it, the engine recognizes the redundancy and collapses it:

ocaml<4.14    AND    ocaml<5.0           ocaml<4.14

 ocaml<4.14          ocaml<5.0            ocaml<4.14
    / \                 / \        →         / \
   F  ~F               F  ~F                F  ~F

                                   Two nodes in, one node out.

Here is the step-by-step:

1. The atoms are ordered: ocaml < 4.14 comes before ocaml < 5.0 (smaller bound).
2. The AND algorithm finds the top atom across both inputs: ocaml < 4.14.
3. Cofactors of the first input w.r.t. ocaml < 4.14: high = True, low = False.
4. Cofactors of the second input w.r.t. ocaml < 4.14: since ocaml < 4.14 implies ocaml < 5.0 (same variable, tighter bound), prune returns True for the high cofactor. The low cofactor remains ocaml < 5.0.
5. Recursive calls: and(True, True) = True for the high branch; and(False, ocaml < 5.0) = False for the low branch, where the terminal case collapses immediately.
6. make_node (ocaml < 4.14) True False is simply the BDD for ocaml < 4.14.

The simplification happened at step 4: prune recognized that ocaml < 4.14 implies ocaml < 5.0 and collapsed the cofactor to True. This turned the low branch into a trivial and(False, ...), and the final result is just ocaml < 4.14.

The test suite checks exactly this collapse (with versions 1.0.0 and 2.0.0; F is the BDD module and && comes from its opened Syntax):

1
2
3
4

(* x < 1 && x < 2 -> x < 1 *)
let lt1 = VersionSyntax.(a < { major = 1; minor = 0; patch = 0 }) in
let lt2 = VersionSyntax.(a < { major = 2; minor = 0; patch = 0 }) in
assert (F.equivalent (lt1 && lt2) lt1);

One syntax, two interpretations #

The previous sections described what the engine does with theory atoms: how it prunes, simplifies, and combines them. This section is about the user-facing API: how OCaml’s module system lets the same syntax code serve two different purposes.

Theo provides syntax modules that let you write constraints naturally:

1
2
3

module V = VersionLeq.Syntax(MyTheory.Left(MyBDD))

let expr = V.(ocaml < version_5_0_0)

The implementation of Leq.Syntax is remarkably concise (ten lines that define six operators):

 1
 2
 3
 4
 5
 6
 7
 8
 9
10

module Syntax (F : Formula with type 'kind desc = 'kind t) = struct
  let lt var limit = F.atom var category (Bound { limit; inclusive = false })
  let le var limit = F.atom var category (Bound { limit; inclusive = true })
  let ( <= ) = le
  let ( < ) = lt
  let ( >= ) v x = F.not (v < x)
  let ( > ) v x = F.not (v <= x)
  let ( = ) v x = F.and_ (v <= x) (v >= x)
  let ( <> ) v x = F.or_ (v < x) (v > x)
end

Notice how >= is just not of < (free, thanks to complement edges), and = is <= AND >= (two bounds). The theory structure maps directly onto the syntax.

The Formula module type is the key abstraction that makes this work:

1
2
3
4
5
6
7
8

module type Formula = sig
  type t
  type _ desc
  val not : t -> t
  val and_ : t -> t -> t
  val or_ : t -> t -> t
  val atom : 'kind Var.t -> 'kind category -> 'kind desc -> t
end

Both Make(T) (the BDD module) and Make(T).Constraint (which builds lists of atomic constraints for the restrict operation) satisfy this interface. So the same Syntax functor works for both (same code, different interpretation):

1
2
3
4
5
6
7

(* Build BDD formulas *)
module V = VersionLeq.Syntax(MyTheory.Left(MyBDD))
let bdd_expr = V.(ocaml < version_5_0_0)

(* Build constraint lists for restrict *)
module V_cstr = VersionLeq.Syntax(MyTheory.Left(MyBDD.Constraint))
let constraint_expr = V_cstr.(ocaml < version_5_0_0)

When multiple theories are combined with Combine(A)(B), the Left and Right projections handle the plumbing. Left(F) wraps the atom descriptor in the Left constructor of the sum type before passing it to F.atom:

1
2
3
4
5

module Left (F : Formula with type 'kind desc = 'kind t) = struct
  include F
  type 'kind desc = 'kind A.t
  let atom var cat desc = atom var cat (Left desc)
end

This allows the syntax helpers for each theory to be blissfully unaware of the combination machinery while producing atoms that are correctly tagged for the combined BDD.

Eliminating variables #

Sometimes you want to ask “does a solution exist regardless of variable x?” without caring about x’s value. In our package manager, this might be: “is there any version of dune that makes this formula satisfiable?” This is quantifier elimination: exists x. f computes the disjunction of f over all possible values of x, effectively projecting x out of the formula.

Theo implements both exists and forall through a single quantify function, parameterized by the combination operator:

1
2

let exists v t = quantify or_ v t
let forall v t = quantify and_ v t

The quantify function walks the BDD, and whenever it encounters an atom for the target variable, it combines the high and low branches with the given operator instead of creating a decision node.

For a boolean variable, this is straightforward. Consider (x AND y) OR (NOT x AND z). Eliminate x (exists x), and you get y OR z. The variable x is gone, and the formula now represents “conditions under which some value of x satisfied the original formula.”

For theory variables, quantifier elimination is more powerful: it removes every atom mentioning that variable, not just a single boolean test. Consider ocaml >= 4.14 AND ocaml < 5.0 AND dune >= 3.0. The BDD for this formula contains two atoms on the ocaml variable (the two bounds). Calling exists ocaml encounters both atoms during traversal and combines their branches at each step. The result is just dune >= 3.0: all version constraints on ocaml have been projected away, leaving only the conditions on other variables.

Contextual simplification #

While prune works locally during construction, we sometimes need to simplify an existing BDD under a set of external constraints. “Simplify this dependency formula knowing that ocaml >= 4.14.” This is the job of restrict.

Theo implements this using a form of partial evaluation. It first converts the list of constraints into a temporary constraint store, a specialized index that records, for every variable, its boolean assignment, its tightest upper and lower bounds (each strict or inclusive), a forced equality value, and a set of excluded values.

Then, it walks the BDD. For each node, it asks the store: “Is this atom’s value forced by the constraints?” The store handles each category differently:

• Leq: it keeps the tightest upper and lower bounds seen for each variable. If the constraint is ocaml < 4.14 and the node tests ocaml < 5.0, the upper bound 4.14 implies the weaker bound 5.0, and the store returns true: the traversal skips directly to the high branch. A lower bound can likewise force the answer to false.
• Eq: it tracks the forced value and the excluded values. If the constraint is name = "foo" and the node tests name = "bar", the store returns false.

For example, restricting (ocaml < 5.0 AND dune >= 3.0) OR ocaml >= 5.0 under the constraint ocaml < 4.14 eliminates both ocaml atoms (one implied, one contradicted) and yields just dune >= 3.0.

The constraint store also detects contradictions eagerly: if the input constraints are mutually inconsistent (e.g., ocaml < 4.14 and ocaml >= 5.0), restrict short-circuits and returns False without traversing the BDD at all.

Optimization as search #

Finding a satisfying assignment for a BDD is easy: just walk down to True. Finding the simplest one (the one that involves the fewest decisions) is harder. But for error reporting, you want to show the user the smallest set of constraints that leads to a conflict, not a verbose dump of every variable.

Theo exploits the canonical DAG structure to solve this via dynamic programming. A memoized pass computes the shortest distance from each node to a satisfying terminal, then a traceback follows the optimal choices. Because identical subgraphs are shared (hash-consing), each node is processed at most twice (once per polarity of the target). The result is not just any witness, but a minimal one: the shortest path through the decision graph, recording one decision per atom tested along the way.

Consider (x0 AND x1 AND x2 AND x3) OR (NOT x0 AND y1). The plain sat function walks down greedily, preferring the high branch at each node, so it commits to x0 = true and has to satisfy the whole conjunction. The shortest path goes the other way:

          x0
         /  \
       y1    x1
      / \   / \
     F  ~F F   x2
              / \
             F   x3
                / \
               F  ~F

sat          finds x0=true, x1=true, x2=true, x3=true   (4 decisions).
shortest_sat finds x0=false, y1=true                    (2 decisions).

Checking without constructing #

Sometimes we want to check a property like logical implication (A implies B) or disjointness (A and B have no intersection) without actually needing the resulting BDD. Constructing the intermediate BDD for (not A) or B just to check if it is True is wasteful: it allocates nodes and pollutes the hash-consing table with entries that will be immediately discarded.

What if you could traverse the BDD as if computing the result, but never actually build it?

Theo addresses this with a dedicated ite_constant engine. It traverses the graph as if it were computing ite(f, g, h), but instead of allocating nodes, it only tracks whether the result is guaranteed to be a boolean constant (True or False) or if it depends on variables (NonConstant). The recursion short-circuits as soon as one branch returns NonConstant: no need to explore the other side.

The three main queries each reduce to a single ite_constant call:

1
2
3
4
5
6

let logical_implies a b =                  (* a => b  ≡  ite(a, b, true) = true  *)
  ite_constant a b true_ = Constant true
let is_disjoint a b =                      (* a ∧ b = ⊥  ≡  ite(a, b, false) = false *)
  ite_constant a b false_ = Constant false
let is_exhaustive a b =                    (* a ∨ b = ⊤  ≡  ite(a, true, b) = true  *)
  ite_constant a true_ b = Constant true

Each is a one-liner. No intermediate BDD is constructed: not a single node is created, and the hash-consing table stays untouched. Verdicts are memoized in the constant cache we saw earlier, and the ite_constant engine even opportunistically checks the regular ITE cache: if a previous full computation already established the result, it reuses it instantly.

From diagrams back to formulas #

A BDD is a great internal representation, but you cannot show one to a user. When a package manager reports why a dependency formula is unsatisfiable, it should print something like ocaml >= 5.0 OR (ocaml >= 4.14 AND dune >= 3.0), not a decision diagram. Formulas of this shape have standard names: an atom or its negation is a literal, a conjunction (AND) of literals is a cube, and a disjunction (OR) of cubes is a sum of products. The formula above is a sum of two cubes.

The irredundant_sop function converts a BDD into an equivalent sum of products, called a cover of the function. And not just any cover: an irredundant one, meaning that dropping any cube, or any literal inside a cube, would change the meaning of the formula. Nothing in the output is noise.

The conversion uses the Minato-Morreale ISOP algorithm. Viewing a boolean function as the set of assignments that satisfy it, the recursion manipulates not one function but an interval [fl, fu]: the cover must contain everything in fl and must stay within fu. The gap between the two is slack: assignments the cover is free to include or not, traditionally called don’t-cares. The top-level call starts with zero slack (fl = fu = the input), but slack appears as the recursion proceeds. At each step, the algorithm splits on the top atom x and emits three groups of cubes: cubes containing the literal NOT x, cubes containing x, and, for whatever the first two groups leave uncovered, cubes that do not mention x at all. That last group is allowed to overlap the other two, and this freedom is what lets cubes carry fewer literals.

Theory support adds a twist here too. Over plain boolean atoms, the cover produced by the recursion is already irredundant. But theory atoms are not independent: since v >= 3 implies v >= 1, the recursion can emit a cube like v >= 1 AND v >= 3 whose first literal is entailed by the second. Interestingly, this redundancy cannot be exploited through the interval’s don’t-cares: the BDD is canonical modulo theory, so impossible atom combinations are already represented by False. The leftover redundancy is purely syntactic, in the cubes themselves. Theo removes it by post-processing: drop every literal entailed by the rest of its cube, then drop every cube whose removal keeps the cover equivalent. Both checks are built on logical_implies and equivalent, which are theory-aware, so the theory reasoning comes for free. A quick structural scan first checks whether any variable carries two distinct theory atoms at all; if not (a common case), the post-processing is provably a no-op and is skipped entirely.

Balanced construction #

When combining a long list of formulas (e.g., and [f1; f2; ...; fn]), the order of operations matters significantly for performance. A naive fold_left tends to produce unbalanced intermediate trees that can grow unnecessarily large.

Theo employs a balanced reduction strategy for n-ary operations. It first sorts the input BDDs by their top variable, a simple heuristic that groups formulas likely to share structure. Why does this help? BDDs that share the same top atom will have matching cofactor decompositions during pairwise combination, so the recursion hits the cache more often instead of recomputing. After sorting, it combines them using a tree-like reduction (pairwise combination) rather than a linear fold. This minimizes the size of intermediate results and further improves cache utilization.

How the pieces fit together #

Theo’s design weaves together several ideas that reinforce each other: complement edges make negation free, which eliminates the need for a dedicated OR algorithm; hash-consing via weak tables provides canonicity without memory leaks; ephemeron-based caches give automatic cleanup when nodes become unreachable; atom ordering by variable and bound value enables theory simplification during construction; and the Formula abstraction unifies BDDs and constraints under the same syntax. Beyond these foundations, techniques like partial evaluation for restrict, dynamic programming for minimal witnesses, construction-free entailment checks, theory-aware irredundant covers for turning BDDs back into readable formulas, and balanced reduction for n-ary operations ensure that the library performs well in practice, not just in theory.

The library is available at github.com/vouillon/theo, with API documentation at vouillon.github.io/theo.

References #

[1] Brace, Karl S.; Rudell, Richard L.; Bryant, Randal E. (1990). “Efficient Implementation of a BDD Package”. Proceedings of the 27th ACM/IEEE Design Automation Conference (DAC 1990). IEEE Computer Society Press. pp. 40–45. doi:10.1145/123186.123222. ISBN 978-0-89791-363-8.
